Ride-on
ARA 85|BM 110
ARA 85|BM 110
Overview
kommt noch
Technical key data
ARA 85|BM 110
Product highlights
Compact construction
Compact ride-on sweeper, ideal for use in densely furnished areas.
Ergonomic machine design
Fatigue-free riding position with good all-round visibility, ideal for longer operating periods and cleaning large areas.
HACCP-compliant
Large inspection openings enable both tanks to be cleaned thoroughly, with ease.
LED on the front
Safe while on the move: all-round visibility while working and when on the move.
Quick-Fill function as standard
Clean water tank can be filled quickly and cleanly via the integrated system coupling.
Optimum access height
Ideal if the operator has to step on and off frequently during long cleaning periods.
ARA 85|BM 110
Optional equipment
Integrated charger
Charge the battery anywhere, with the high-quality integrated charger.
ECD – electronic Chemical dosing system
Only as much chemicals as absolutely necessary; this is good for the environment and the budget.
Security-Kit
Maximum operational safety due to rotating beacon.
Blue Spot
Greater safety when working alongside industrial trucks
Manual suction tool
Thorough cleaning, even in difficult areas.
Comfort seat with armrests
Even more comfort during long operations.
ARA 85|BM 110
Technical data
| Technical key data | |
|---|---|
| L x W x H | 1450 x 890 x 1285 mm |
| Working width | 850 mm |
| Suction width | 980 mm |
| Theoretical coverage max. | 5950 m²/h |
| Noise level | 62 dB(A) |
| Empty weight | 245 kg |
| Operating weight | 627 kg (305 Ah 5) |
| Tank | |
|---|---|
| Solution tank capacity | 110 l |
| Recovery tank capacity | 120 l |
| Brushes and pad holders | |
|---|---|
| Number | 2 Disc brushes |
| Diameter | 430 mm |
| Speed | 180 rpm |
| Brush pressure | 35 / 60 kg |
| Batteries / Electrical data | |
|---|---|
| Rated voltage | 24 V |
| Power max. | 2410 W |
| Capacity gel | 305 Ah 5 |
| Number of single blocks | 4 pieces |
| Working time | 4,5 hours |
| Suction motor | |
|---|---|
| Nominal power | 510 W |
| Low pressure | 168 mbar |
| Air flow | 30 l/s |
| Traction motor | |
|---|---|
| Power | 750 W |
| Speed | 7 km/h |
