Industrial vacuums

IDV 60 eco

IDV 60 eco

Overview

This three-phase industrial dry vacuum cleaner is the ideal tool for almost all industries and heavy-duty applications. Equipped with a maintenance-free side channel blower, it is designed for continuous operation (24/7). With a wide range of equipment options, it covers a wide performance spectrum: for example, filtration stages of dust class L, M, H, and HEPA as well as safe disposal systems for toxic dusts according to EN 60335-2-69, also available in stainless steel.

Technical key data
  • Tank capacity 60 l

  • Power max. 2,3 kW

  • Three-phase current
  • Dry / wet dry

IDV 60 eco
Product highlights
Vielseitig reinigen
Epoxy-lacquered steel

Robust construction: for industrial use and extreme requirements.

Vielseitig reinigen
Removable ride-on container

Collected dirt can be emptied quickly and easily.

Vielseitig reinigen
Three-phase A.C. current-motor with side channel blower

Maintenance-free and with a long service life: The three-phase A.C. current-motor is sized for continuous industrial operation. The air flow is compressed twice to achieve greater suction power.

Vielseitig reinigen
Polyester star filter as standard

20,000 cm² filter area for a long service life.

Vielseitig reinigen
Manual filter cleaning system

Easily accessible from the exterior: the efficient filter system means longer operating periods and constant, excellent suction results.

Vielseitig reinigen
Negative Pressure Gauge

Continuous control of proper operation and filter assignment.

more features
  • Non-marking rollers

Leaves no trace behind: ideal for use at any industrial site.

  • Locking brake

Maximum safety in stationary operation and when emptying.

  • Ergonomic lever-operated emptying

The suction container is very easy to empty and remove.

  • Compact design

Ideal for mobile dust removal, whether in the construction industry or when cleaning buildings.

less features
IDV 60 eco
Optional equipment
Vielseitig reinigen
Filter Dust class M

Recommended for filtering wood dusts, paint particles and various metal dusts. Filters with dust class M are particularly recommended for intensive work with wood.

Vielseitig reinigen
Filter Dust class M Teflon

Filters with dust class M and PTFE are particularly recommended for the collection of fine particles.

Vielseitig reinigen
Filter Dust class H

Suitable for the filtration of hazardous and carcinogenic substances such as mould spores, lead dust and various types of mineral fibres.
Recommended for ATEX Zone 21.

Vielseitig reinigen
HEPA Filtration

Maximum protection against fine dust.

Vielseitig reinigen
Filter antistatic class M

Recommended for filtering wood dusts, paint particles and various metal dusts. The dust class M is especially recommended for intensive work with wood, in antistatic design in combination with the earthing option.

Vielseitig reinigen
ATEX, explosion-proof

Explosion-protected for use in highly explosive areas. – ATEX zones 1, 2, 21 or 22.

more options
  • Stainless steel container V2A

The stainless steel version is ideal for use under harsh conditions.

  • Stainless steel container V2A with filter chamber

For special applications (e.g. laboratory conditions) the complete equipment in stainless steel is optimal.

  • Various suction hose lengths and materials on request

A wide range of hose lengths and materials are available for different applications.

  • Further configurations on request

We can configure the appropriate industrial vacuum cleaner for almost all extraction tasks on request.

less options
IDV 60 eco
Technical data
Technical key data
L x W x H 660 x 650 x 1700 mm
Tool connection 80 mm
PVC hose 3 m/50 mm
Tank volume 60 l
Filter surface area 20 000 cm²
Filter type Star / pocket / polyester
Filter dust class CAT (BIA)
Weight 80 kg
Electrical data
Rated voltage 400 V
Power total 2,3 kW
Mains cable 10 m
Suction motor
Low pressure max. 3000 mm H²O
Air flow max. 300 m³/h
Number of motors 1
